zawory kulowe KLINGER Monoball® KHM

zawory kulowe KLINGER Monoball® KHM

Jednoczęściowe, wielofunkcyjne, niezawodne i bezobsługowe.

The KLINGER Monoball ball valve made of steel is a multifunctional, durable and fully welded shut-off valve which is uncompromisingly designed for applications in district heating, heating, air-conditioning technology and general plant construction. Available in different connections (flanges, weld- and threaded ends).

The elastic joint seal, maintenance-free double sided sealing system with non-corrosive stainless steel spring, the usage of stainless steel ball, operating stem, the graphite reinforced PTFE seat rings, guarantee a long lifetime, ensure reliability and low costs of operation.



Product advantages Monoball KHM

  • Always safe in service and reliable tight
  • Maintenance free
  • Ball and operating stem made of stainless steel
  • No creeping in of the operating medium under pressure
  • Stem sealing by O-rings made of high quality elastomer
  • Burst-proof and blow-off safe mounted operating stem, placed in a PTFE+C bush
  • Selfinhibitive through specially placed spring washer
  • Operating position of the ball can still be identified even when the hand lever is removed

Special types Monoball KHM

  • Top flange for mounting of mechanical gear
  • Operating shaft extension resp. set for underground installation
  • Extension adapter for stem

Szczegóły produktu

PN 16/25/40
DN 10 – 150 (weitere Nennweiten auf Anfrage)
Material C-Stahl und Edelstahl
Temperature 0 °C bis +200 °C
Design Schweißenden, Flansche, Gewindemuffen, Außengewinde und kombiniert, voller und reduzierter Durchgang, Handhebel, Sechskant, Unterflureinsatz
Type Einteiliger Kugelhahn

Katalogi do pobrania

Poniżej możesz pobrać broszurę informacyjną na temat ich producenta zaworów kulowych Monoball KHM - KLINGER Fluid Control, zawierającą m.in. informację na temat zaworów kulowych Monoball KHM.

Image brochure KLINGER Fluid Control (2.6 MiB)
